| Business Type | Manufacturer, Exporter, Supplier |
| Material | Stainless Steel |
| Brand Name | ELTEC |
| Accuracy | CLASS 1 |
| Click to view more | |
Product Details
Application
Used As Temperature Sensor
Temperature Range
Upto 1200 C
Dimension
As Per Client Requirement
Mounting
Adj. Ferrule Fitting 1/2 BSP / 1/2 NPT Etc.
Stem Length
As Per Client Requirement
Protection Sheath
SS 316 / SS 310 / INCONEL 600 / AISI 321 / AISI 347
Stem Dia
1.5mm / 3.00 Mm / 4.5.00 MM / 6.00 Mm / 8.00 Mm
Insulation
Mineral Insulated
Thermocouple Calibration
J / K / T / E / N
Application
- Immersion in liquids
- High Moistures Applications
- Corrosive Gases, Oils & Petrochemical Industries
- Power, Steel & Sponge Iron
- Temperature Measurement in Chemical Reactors
- General Industrial Applications
Features
- Wider Temperature Range up to 1100 ºC
- Can be easily bent, flattened or twisted
- SS Sheathing coupled with tightened magnesia ensure longer life
- High Die Electric Strength
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Faster Response
Looking for "Mineral Insulated Thermocouple" ?
