Temperature Sensor Thermocouple
Leading Manufacturers, Exporters and Wholesaler of Bayonet Type Thermocouple, Bolt Type Thermocouple, Flexible And Bayonet Thermocouple, High Temperature Sensor, Mineral Insulated Thermocouple, Pencil Type Thermocouple, Ring Lug Type Thermocouple and Sheathed Base Metal Thermocouple With Connection Head from Rajkot.
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Stainless Steel |
| Application | Industrial |
| Type | Thermocouple |
| Mount | Bayonet |
| Probe Material | Stainless Steel |
| Probe Termination | Lead Wire |
| Probe Diameter | 0.5 - 8 Mm |
| Probe Length | 0 - 150 Mm |
| Junction Type | Ungrounded |
| Configuration | Simplex |
| Material Grade | SS304 |
| Insulation | FIBER GLASS / PTFE / FEP / PFA |
| Temperature Range | 0 To 400 Deg C |
| Accuracy | +/- 1.5 Deg C Or +/- 0.4% |
| Cable Total Length | As Per Client Requirement |
Application
- Plastic Extrusion Machines, Diversified Plastic & Packing Machinery
- Automobiles & Engine Testing, Gen set
- Medical & Scientific Equipments
- Pharma, Food & Beverages
- Various Industrial Machineries
- Measuring Bearing Temperature in Motors, Turbines etc.
Features
- Bayonet fixtures with spring and adaptors for quick & easy attachment & detachment
- Adjustable Lengths & Fixed Lengths
- Wide Industrial applications
- Easy to use in hanging applications.
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Customized probes for measuring temperature for critical industrial applications
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Stainless Steel |
| Application | Industrial |
| Type | Thermocouple |
| Mount | Bolt Type |
| Junction Type | Ungrounded |
| Configuration | Simplex |
| Insulation | Fiber Glass |
Application
- Plastic Extrusion Machines, Diversified Plastic & Packing Machinery
- Automobiles & Engine Testing, Gen set
- Medical & Scientific Equipments
- Pharma, Food & Beverages
- Various Industrial Machineries
- Measuring Bearing Temperature in Motors, Turbines etc.
Features
- Screwed bolts for quick & easy attachment & detachment
- Adjustable Lengths & Fixed Lengths
- Wide Industrial applications
- Easy to use in hanging applications.
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Customized probes for measuring temperature for critical industrial applications
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Eltec |
| Application | Industrial |
| Accuracy | +/-1.5 Deg C Or +/-0.4% |
| Class | Class 1 |
| Probe Material | Stainless Steel |
| Assembly | Thermocouple Probe |
| Mount | Bayonet |
| Probe Termination | Miniature Plug |
| Probe Diameter | 9 - 20 Mm |
| Temp Range | -50 To 450 Deg C |
| Model | TC FLEXIBLE |
Application
- Plastic Extrusion Machines, Diversified Plastic & Packing Machinery
- Automobiles & Engine Testing, Gen set
- Medical & Scientific Equipments
- Pharma, Food & Beverages
- Various Industrial Machineries
- Measuring Bearing Temperature in Motors, Turbines etc.
Features
- Locking cap / spring / screwed bolts for quick & easy attachment & detachment
- Adjustable Lengths & Fixed Lengths
- Wide Industrial applications
- Easy to use in hanging applications.
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Customized probes for measuring temperature for critical industrial applications
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Alumina |
| Sheath | High Temperature Alumina / Inconel 600 |
| Temperature Range | 0 TO 1750 C |
| Thermal Accuracy | Class 1 |
| Type Of Thermocouple Calibration | K, N, R, S, B |
| Insulation | Cermaic / Mineral Insulated |
Introducing our High Temperature Sensor, designed for extreme conditions. Made of Alumina with a High Temperature Alumina / Inconel 600 sheath, it offers a wide temperature range of 0 to 1750°C. With a thermal accuracy of Class 1 and Type K thermocouple calibration, this sensor ensures precise and reliable temperature measurements in high-temperature environments.
Read More...
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Stainless Steel |
| Brand Name | ELTEC |
| Accuracy | CLASS 1 |
| Application | Used As Temperature Sensor |
| Temperature Range | Upto 1200 C |
| Dimension | As Per Client Requirement |
| Mounting | Adj. Ferrule Fitting 1/2 BSP / 1/2 NPT Etc. |
| Stem Length | As Per Client Requirement |
| Protection Sheath | SS 316 / SS 310 / INCONEL 600 / AISI 321 / AISI 347 |
| Stem Dia | 1.5mm / 3.00 Mm / 4.5.00 MM / 6.00 Mm / 8.00 Mm |
| Insulation | Mineral Insulated |
| Thermocouple Calibration | J / K / T / E / N |
Application
- Immersion in liquids
- High Moistures Applications
- Corrosive Gases, Oils & Petrochemical Industries
- Power, Steel & Sponge Iron
- Temperature Measurement in Chemical Reactors
- General Industrial Applications
Features
- Wider Temperature Range up to 1100 ºC
- Can be easily bent, flattened or twisted
- SS Sheathing coupled with tightened magnesia ensure longer life
- High Die Electric Strength
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Faster Response
| Business Type | Manufacturer, Exporter, Supplier |
| Application | Industrial |
| Material | SS |
| Assembly | Thermocouple Probe |
| Junction Type | Ungrounded |
| Configuration | Simplex |
| Type Of Sensor | J / K / T |
| Accuracy | +- 1.5 DegreeC Or +- 0.40% |
| Temperature | 0 To 250 C |
| Wire Length | 2 Mtrs. / 5 Mtrs. Or As Per Client's Requirement |
| Probe Length | 6 X 250 Or As Per Client's Requirement |
| Type Of Probe | Pencil Type |
Introducing the Pencil Type Thermocouple, a reliable industrial temperature sensor made of high-quality SS material. This thermocouple probe features an ungrounded junction type, simplex configuration, and offers accurate temperature readings with an error margin of +- 1.5 DegreeC or +- 0.40%. Available in J, K, or T sensor types for versatile industrial applications.
| Business Type | Manufacturer, Exporter, Supplier |
| Accuracy | CLASS 1 |
| Material | Stainless Steel |
| Application | Industrial |
| Temperature Range | 0 To 450 C |
| Country of Origin | India |
| Mounting | Ring Lug |
Application
- Plastic Extrusion Machines, Diversified Plastic & Packing Machinery
- Automobiles & Engine Testing, Gen set
- Medical & Scientific Equipments
- Pharma, Food & Beverages
- Various Industrial Machineries
- Measuring Bearing Temperature in Motors, Turbines etc.
Features
- Locking cap / spring / screwed bolts for quick & easy attachment & detachment
- Adjustable Lengths & Fixed Lengths
- Wide Industrial applications
- Easy to use in hanging applications.
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Customized probes for measuring temperature for critical industrial applications
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Eltec |
| Application | Industrial |
| Accuracy | +/- 1.5 Deg C Or +/- 0.4% |
| Temperature Range | 0 To 1250 Deg C |
| Probe Material | Stainless Steel |
| Assembly | Thermocouple Head Assembly |
| Mount | Threaded |
| Junction Type | Ungrounded |
Application
- General Purpose but especially appropriate for severing & demanding conditions
- Salt Baths, Heat Treating and Molten Metal Applications
- Temperature Measuring Instrument for Boilers & Other Temperature & Pressure Vessels
- Temperature Measurement in various type of furnaces
- Temperature Measurement in Chemical Reactors
- General Industrial Applications
Features
- Wider Temperature Range up to 1100 ºC
- Heavy Wall to provide long life of thermocouple in harsh conditions
- Variety of Pipe Material for use in different atmospheres
- Easy to use in hanging applications.
- Thermal Accuracy as per ANSI MC 96.1 & ASTM E230
- Faster Response
